5-Band Sound Processor
Directly in Your Transmitter

The first stage of the processor is an automatic gain control which regulates the perceived volume level of the station output across all audio sources and formats. It uses predictive algorithms and protects against unwelcome increases in noise.

The AGC is followed by enhancers which embellish both the low and high frequencies. Combined with 3 parametric equalizers, they enable the creation of a distinct sonic signature.

A stereo enhancer can be used to improve the stereo image of your station when using non-mono content. It also includes a stereo limiter to improve the quality of your station in areas with problematic coverage.

The 5 Band Processor dynamically adjusts the gain of each audio band. Depending on the selected preset, it can work as a slow and purist multi-band leveler, or as a fuller processor to create a strong sonic signature. The fidelity parameter enables you to fine tune the bands according to your preference; from a purist sound to a more colored texture.

5 limiters have been designed to facilitate the work of the final clipper. For soft formats, the limiters provide smooth protection for your final audio and for commercial stations, they can be used to create extra loudness.

This section uses several limiters including HF and final low distortion limiters. In addition, and independently of any preset, the ECRESO FM Transmitter can be configured with an MPX Power Limiter and a deviation Hard Clipper for transmitter protection.
